Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160

  • Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160
  • Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160
  • Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160
  • Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160
Place of Origin China
Brand Name HDFocus
Certification CE,ROHS,FCC,HDMI
Model Number HD-65I-T049
Minimum Order Quantity 1
Price $520.00 - $1180.00
Packaging Details Plastic protective film, carton,wooden box
Delivery Time 5-15 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 10000PCS/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Aspect Ratio 16:9 Resolution 3840*2160
Writing Method Pen/finger Touch Touch IR Touch With 20 Points
Software Whiteboard Software/Screen Share/More Material Aluminum Edging+Toughened Glass
Connectivity LAN, WIFI, USB, Touch,HDMI, Multi Input Power Less Than 135W
High Light

Multipurpose Smart Interactive Panel

,

Classroom Smart Interactive Panel

,

Touch Board For Classroom 3840×2160
Leave a Message
Product Description

Dual System 4k Resolution 60hz Android 11 Multifunction Smart Whiteboard

All-in-one Computer Real-time Interactive Whiteboard



  • ADVANCED HARDWARE PERFORMANCE: Adopt 4K UHD PCAP touchscreen, 32G SSD and Dual system. Built-in 5G module. The more powerful capacity and Chromium OS ensure Vibe Interactive Smart board enjoyable and convenient experience
  • Real-Time Collaboration and Screen Share: Soulaca Smart Interactive Whiteboard perfectly supplements your existing Zoom, Google Meet, Microsoft Teams, Webex and other popular 3rd party video conferencing meetings with enhanced remote presentation & whiteboarding capabilities
  • Present and annotate: HDFocus smart board supports up to 4 users to screencast simultaneously via Airplay and Eshare, or by connecting in via HDMI. With your screen cast, you can annotate as needed, share via video conferencing, or pin screenshots.

Color
Black
Screen Size
55", 65", 75", 85", 86", 98", 100"
Resolution
4K 3840*2160
Operation System
Android / Windows (Dual system)
Touch Type
Infrared 20 touch points
Interface
HDMI 2.0,VGA,TV-RF,USB 2.0,USB3.0,TF card,AV,RGB,RS232,Touch Port,Earphone,SPDIF









Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 0
Products Description
Dual System 4K resolution 60hz Android 11 Multifunction Smart Whiteboard
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 1




Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 2
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 3

Interactive smart board, comes with professional whiteboard software under Android OS, like

video recording, annotation share by QR code, floating Menu, etc.Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 4

Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 5
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 6
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 7
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 8
Application

Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 9
Education
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 10
Meeting Room
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 11
Distance Learning
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 12
News Broadcast
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 13
Live Stream
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 14
Video Conference
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 15
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 16
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 17
Specification
Panel Size
55/65/75/85/86/98/100 inch
Resolution
4k 3840×2160
Panel back light
TFT-LCD Module
Panel Protection
Tempered Glass, Anti-Glare glass
Picture scale
16:9
refresh frequency
60Hz
Panel Specification
1.07B(10bit)
Gamut NTSC(Typ)
72%
contrast ratio(Typ)
5000:1
Backlight Type
DLED
Life Span
≥30000 hours

Android Configuration
CPU
ARM Cortex A73*2 and A53*2
GPU
Dual core Mali-G51
RAM
4GB
ROM
32GB
WIFI
2.4GHz/5 GHz
Bluetooth
Support
Android OS
Android 8.0
Input/output
HDMI 2.0,VGA,TV-RF,USB 2.0,USB3.0,TF card,AV,RGB,RS232,Touch Port,Earphone,SPDIF

Windows Configuration
CPU
i3/i5/i7
RAM
4/8/16/32 GB DDR4
Internal memory
128/256/512 GB SSD
Windows OS
Windows 7, 8.1, 10
HDMI
HDMI 2.0
USB
USB 2.0*4, USB 3.0*2
RJ45 Port
RJ45*1
WIFI
2.4GHz/5 GHz

Touch Screen
Touch Type
Infra-red
Points
20 points
Response Time
Less than 5ms
Touch Way
Pen, Finger or other
Position Accuracy
±1mm
Resolution
32767 * 32767

Others
Accessories
Remote Controller.Wall Mount RackerTouch Pen.User Manual.Power cable
Speaker
8*12W speakers (Front)
Pixel camera
800/1200 Mil
Product Packaging
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 18
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 19
Customer Review
Multipurpose Smart Interactive Panel , Touch Board For Classroom 3840×2160 20
FAQ
1. Who are we?
We are based in Guangdong, China, start from 2013,sell toNorth America(40.00%),Southeast Asia(18.00%),South America(12.00%),Africa(8.00%),Mid East(7.00%),North America(5.00%),Eastern Europe(5.00%),South Asia(5.00%). There are total about 51-100 people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
Advisement Kiosk,All in One Touch Screen PC for Education & Conference Use,Nano Interactive LED Blackboard

4. Why should you buy from us not from other suppliers?
Because we are a manufacturer with 16 years of production experience, we have a complete set of plans and professional personnel to provide technical support, and the bid is confirmed. Choose us as your most cost-effective solution

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,CNY；
Accepted Payment Type: T/T,L/C,Cash;
Language Spoken:English,Chinese,Cantonese.
Accepted Payment Type: T/T,L/C,Cash;
Language Spoken:English,Chinese,Cantonese









Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,Cash;
Language Spoken:English,Chinese,Cantonese



Why can a conference tablet replace a projector?



The conference tablet is a new type of conference machine. Now, an intelligent conference service platform has already emerged, which takes the conference tablet as the main body of behavior, and is equipped with screen sharing devices, smart pens, video conference system modules and other functions to expand spare parts. The product attributes of the conference tablet overlap with the aspect ratio of the projector, which is an ideal substitute for the projector. Many well-known conference tablet brands are called the "ultimate projector" in the publicity and promotion of opening up. So what are the advantages of conference tablets compared with projectors?




1: Picture transmission and data transmission method


The projector must be connected to the computer with VGA cable or HDMI cable, so as to promote the picture on the computer to the projection screen. Because of the limitation of the cable port number, the projector can only connect to the computer.


The image transmission technology of the conference tablet is wireless screen sharing, which can connect to the computer according to the screen sharing device. It can also be connected to mobile devices such as mobile phones and tablets according to the projection software. The meeting board is applicable to four machines. The content of the equipment is divided into four parts, which shows that the comparison is more visual and eliminates the wiring trouble
